CR-HC701X, Stationary Barcode Reader Embedded Integrated Electronic Code Reader

Name: CRHC701X Stationary Barcode Reader Embedded Integrated Electronic Code Reader
Brand: SUPERISYS
Price: 1 USD

Ask Latest Price

Video Channel

Brand Name :SUPERISYS

Model Number :CR-HC701

Certification :ISO\FCC\ROSH

Place of Origin :CHINA

MOQ :one

Price :Large quantity price negotiable

Payment Terms :T/T, Western Union

Supply Ability :1000 per day

Delivery Time :5-8 Work Days

Stock :In Stock

Description :Fixed code reader，

size :56.5(width)x56(height)x30(depth)

weight :250g

power supply mode :5-30V DC+/-10%,500mA

power loss :peak <2.5W, average 2W

system architecture :ARM926

Image data format :JPEG

Sensor type :Global Shutter CMOS

focal length :5mm/ 16mm/6mm/12mm

software :Fixed 1D/QR code reading, challenging 1D/QR code reading, including DPM

resolution ratio :WVGA 1280*800

frame rate :60 fps

Image color :mono

secondary light source :8 high brightness LED

interface type :RS232, USB-virtual-COM, USB-keyboard，Ethernet

Motion tolerance :2m/s

Recognition accuracy :min. 2mil

Read code system :1D code: Code 128, Code 39, Code 93, Code 11, Matrix 2 of5, Interleaved 2 of 5.Codabar, MSI Plessey, GS1 DataBar, China Postal, UPC, EAN etc2D code: PDF 417, MicroPDF417, DataMatrix, Maxicode, QR code, MicroQR, Aztec,Hanxin, Vericode*，etc.

temperature :Operating: -30°C to 60°C, Storage: -40°C to 70°C

humidity :0% to 90% relative humity no-condenssing

IPclass :IP65

Contact Now

Add to Cart

View Product Description

CR-HC701X,Stationary Code Reader

Product characteristics

New upgrade, better performance, better decoding ability

Vericode code compatibility

Enhanced image contrast with high light LED

Multiple sets of parameters, better deal with mixed line production

Modular installation, support to change the M-port lens

IP65 rating

A variety of customization solutions, supporting various scenarios

Supports a variety of communication methods,

Support Modbus,PN,MC,EthernetIP protocols

Application field

Precisely adapted to 3C electronic manufacturing, embedded and integrated into various ICT, FCT, various test fixtures and non-standard automation equipment.

Seamless access to MES and WMS and other production information system bar code information static reading collection points.

model	CR-HC701X-05R	CR-HC701X-16R	CR-HC701X-06RA	CR-HC701X-12RA
size	54(width)x53(height)x15.25(depth)
weight	250g
power supply mode	5-30V DC+/-10%,500mA
power loss	peak <2.5W, average 2W
system architecture	ARM926
Image data format	JPEG
Sensor type	Global Shutter CMOS
software	Fixed reading 1D/QR codes, reading challenging 1D/QR codes, including DPM
focal length	5mm lens fixed focal length	16mm lens fixed focal length	6mm lens auto zoom	12mm lens auto zoom
resolution ratio	WVGA 1280*800
frame rate	60 fps
Image color	mono
secondary light source	8 high brightness LED
interface type	RS232, USB-virtual-COM, USB-keyboard,Ethernet
Motion tolerance	2m/s
Recognition accuracy	min. 2mil
Read code system	1D code: Code 128, Code 39, Code 93, Code 11, Matrix 2 of5, Interleaved 2 of 5.Codabar, MSI Plessey, GS1 DataBar, China Postal, UPC, EAN etc2D code: PDF 417, MicroPDF417, DataMatrix, Maxicode, QR code, MicroQR, Aztec,Hanxin, Vericode*,etc.
temperature	Operating: -30°C to 60°C, Storage: -40°C to 70°C
humidity	0% to 90% relative humity no-condenssing
IPclass	IP65
size
